    Hello Beoworlders,

    Following Matador’s advice, I tested the still “functional” drive with several discs.

    There is no logic in the results, as some CDs with a lot of tracks work fine and some don’t.

    On a few of them, the discs is read for a few seconds then stops.

    In one case on a short disc, the sound was highly distorted.

    I suspect that tuning of the CDM2 laser is not adapted to the CDM4 servo board.

    Any advice?

    Kind regards,

    Yann.









    in reply to: Help needed from Martin or other CD drive specialists #7443
    YannChris
    GOLD Member
    • Brittanny, France
    • Topics Started 7
    • Total Posts 48

    Hello Beoworlders,

    To Matador: I did not test a lot of CDs as I was unsure that the mix between lasers and servo boards was safe.

    To all: I went further on the CD150 alternative solution and found that the grey 14 pins connector of the Beocenter’s drive is split in two separate connectors (9 + 4 pins) on the Philips one.

    The last option is to send my drives to someone who is able to repair them.

    Anybody interested?

    Kind regards,
    Yann.

    in reply to: Help needed from Martin or other CD drive specialists #7429
    YannChris
    GOLD Member
    • Brittanny, France
    • Topics Started 7
    • Total Posts 48

    Hello Beoworlders,

    To Martin: Sorry but I could not localize the smell.
    I always carefully removed the ribbon cables using the ZIF connector on the servo board.
    I agree with you, there are sharp angles on the CDM 4 and I hope that the seller took care when he recapped the unit.

    To all: Today, I exchanged the laser units from one drive to another, here are my findings:

    CDM 4 servo with CDM 2 Laser: plays well on an 8 tracks CD except a noise when moving to a track at the end of the CD, but does not work on a 18 tracks one. This behaviour was identical on original CDM 2 unit before the “smell incident”. See these videos:


    CDM 2 servo with CDM 4 Laser: same symptom as on full CDM 2 unit after the “smell incident”. See this video:

    I come to the conclusion that something is wrong on both servo boards as no perfect result is obtained.

    When it comes to lasers, I suppose they are still functional, but I suspect the CDM 2 one needs some tuning and I have neither knowledge and equipment to proceed. I have no idea for CDM 4.

    So “I send an SOS to the world” and would be grateful if somedy with the know-how could take over this repair. Of course, I take all the costs.

    Thanks by advance and kind regards,

    Yann.

    in reply to: Report Problems with the Site Here #7417
    YannChris
    GOLD Member
    • Brittanny, France
    • Topics Started 7
    • Total Posts 48

    Hi Keith,

    After editing, my last post has been marked as spam and does not appear anymore.

    What to do?

    Kind regards,

    Yann

    in reply to: Help needed from Martin and vintage products specialists #6940
    YannChris
    GOLD Member
    • Brittanny, France
    • Topics Started 7
    • Total Posts 48

    Thank you Martin.

    The set was VERY dirty when it arrived with a lot of dust inside that I removed with a paining brush and the aluminium lids also need a deep cleaning.

    What product can I use to do this?

    Kind regards,

    Yann.

    in reply to: New feature: B&O Radio can now be used by ASE products #6921
    YannChris
    GOLD Member
    • Brittanny, France
    • Topics Started 7
    • Total Posts 48

    Hi MM,

    Same for me.

    Regards,

    Yann.

    in reply to: Beolink 5000 E-Ink screen repair / mod #6847
    YannChris
    GOLD Member
    • Brittanny, France
    • Topics Started 7
    • Total Posts 48

    Hi Beoworlders,

    Recieved today my Beolink 5000 updated by Pilatomic.

    Great job, everything works fine!

    The remote control has now a Beo4 look with the screen always on.

    Regards,

    Yann.

    in reply to: idler wheel anyone please? #6835
    YannChris
    GOLD Member
    • Brittanny, France
    • Topics Started 7
    • Total Posts 48

    Wrong post, sorry.

    • This reply was modified 3 weeks ago by YannChris.
    YannChris
    GOLD Member
    • Brittanny, France
    • Topics Started 7
    • Total Posts 48

    Hi,

    Thanks Peter and Chartz for your informations.

    As I am not particularly skilled with my hands, I’m not very confident in swapping the idlers.

    Chartz, I understand what you mean, but I don’t see how to identify which idler is the loudest and how / where to put it.

    I think it’s more sensible to digitize my tapes first and will update this thread once done.

    Thanks again,

    Yann.









    • This reply was modified 3 weeks, 6 days ago by YannChris.
    in reply to: A question for Geoff Martin on BL8000 Damping… #6730
    YannChris
    GOLD Member
    • Brittanny, France
    • Topics Started 7
    • Total Posts 48

    Hi Beoworlders,

    That’s it, my BL 8000 are now finished:

    After an extensive cleaning following Matador’s tutorial:

    -New damping material placed,

    -Foam tape exchanged with Beobuddy’s supply,

    -Bushings of the main transformers exchanged by new ones supplied by Beoparts (part number RP-008  proposed for BL Penta, 3000, 4500, 5000).

    They shine like new!!!

    My warmest thanks to all contributors of this brilliant thread,

    Yann.



    YannChris
    GOLD Member
    • Brittanny, France
    • Topics Started 7
    • Total Posts 48

    Thanks Omminp.

    You were right… again 🙂

    3 rubber buffers were broken in two parts, the 4th was the only still in one piece.

    3 drops of loctite made the job, I feel more secure now.

    While the set was opened, I took videos of the moving parts at the 3 speeds. The belt on the right side moves strangely. The set is more noisy when “closed”.

    Videos are online on this playlist, if you can’t reach them just tell me:  https://youtube.com/playlist?list=PL5Sdc5VmHaOJJCaNR6syj5EfxE5SZrQ_H

    PS: The type stated on the schematic is 4136 50 Hz

    Kind regards,

    Yann.

    • This reply was modified 1 month ago by YannChris.
    • This reply was modified 1 month ago by YannChris.
    • This reply was modified 1 month ago by YannChris.
    • This reply was modified 1 month ago by YannChris.
    • This reply was modified 3 weeks, 3 days ago by YannChris.
    YannChris
    GOLD Member
    • Brittanny, France
    • Topics Started 7
    • Total Posts 48

    Hello Beoworlders,

    Chartz and Omminp, thanks for your precious informations.

    I opened the set and cleaned what I could, including the heads which seem to be OK.

    I did not put oil on the idlers, as I don’t know which kind of oil to use.

    The exchange of capacitors is unfortunately out of my competence.

    The connection from Beocenter to the Radio input on the BC 2000 works.

    I kept a connection from the Line socket to an USB soundcard and tested the recording on a laptop. Test was successful.

    Good surprise, a small envelope containing the schematic is stuck inside of the bottom plastic case.

    2 problems remain:

    1: I cannot find how the chassis is held on the wooden frame. I found one screw on the right side, underneath the headphone jack but could not find anything on the left side.

    So if I place the set vertically, the chassis tends to get out.

    Unfortunately the service manual available on the old site is in German and I don’t speak this language.

    2: The set is rather silent on low speed, more noisy on middle speed and supersonic on high speed.

    It does not work when placed vertically.

    Could a video help someone to diagnose where the defect stands?

    Thanks for your help,

    Yann.

    in reply to: Beocenter 9000 codes #6655
    YannChris
    GOLD Member
    • Brittanny, France
    • Topics Started 7
    • Total Posts 48

    Hi,

    Nobody to help me?

    Kind regards,

    Yann.

    YannChris
    GOLD Member
    • Brittanny, France
    • Topics Started 7
    • Total Posts 48

    Hi all,

    I tested the set and bought it.

    By chance, the heads are not worn out, so I can play the tapes.

    But Chartz was right, idler wheels must be hard and the BeOcord sounds as a BOeing 🙂

    As my project is to digitalize the tapes it is not so annoying.

    By chance, the line-out works but the plug is wired in a strange way, as input and output pins seem to be reversed.

    So to connect it to my Beocenter 9000, I have to fiddle with Din/RCA/Din adapters.

    Tomorrow I’ll check the speaker outputs.

    Kind regards,

    Yann.

    in reply to: Report Problems with the Site Here #6583
    YannChris
    GOLD Member
    • Brittanny, France
    • Topics Started 7
    • Total Posts 48

    Hi Keith,

    A bit off-topic, excuse me but I don’t know who to contact.

    In the old site, the service manual of LC1 just shows 1 page.

    I have the feeling that the file is not complete.

    Is it possible to check?

    Kind regards,

    Yann.



    YannChris
    GOLD Member
    • Brittanny, France
    • Topics Started 7
    • Total Posts 48

    Hello Martin,

    Thanks for the info, my mistake is corrected.

    Do you have any clue for the remaining problems?

    Does the reading of the tork-meter tape video shows something useful?

    Kind regards,

    Yann.

    • This reply was modified 1 month ago by YannChris.
    YannChris
    GOLD Member
    • Brittanny, France
    • Topics Started 7
    • Total Posts 48

    Update:

    I exchanged the belt with a one bought to Dillen a few years ago but never used.

    Unfortunately with no complete result : fluctuations while reading are gone but the other defects stay unchanged.

    Any clue?

    Kind regards,

    Yann.

    • This reply was modified 1 month ago by YannChris.
    YannChris
    GOLD Member
    • Brittanny, France
    • Topics Started 7
    • Total Posts 48

    And did the videos give you other clues?

    YannChris
    GOLD Member
    • Brittanny, France
    • Topics Started 7
    • Total Posts 48

    Thanks Chartz,

    I just had a look and these parts are for Beocord 9000 and I have a Beocenter 9000

    Are you site they are adapted to my set?

    Kind regards,

    Yann

    YannChris
    GOLD Member
    • Brittanny, France
    • Topics Started 7
    • Total Posts 48

    Thanks Chartz,
    What do you mean by tyres?

    Kind regards,

    Yann.
